PS2 Joystick Module Breakout Sensor
Versatile dual-axis analog joystick module identical to those found in PlayStation 2 controllers. This breakout sensor provides precise X-Y axis position data plus a built-in push-button switch, making it ideal for robotics control, gaming projects, and interactive interfaces with Arduino, ESP32, and Raspberry Pi. Premium quality from The Engineer Store, Bengaluru. Fast shipping, 7-day warranty on manufacturing defects, and dedicated technical support.
Specifications
| Module Type | Dual-Axis Analog Joystick with Push Button |
| Operating Voltage | 3.3V - 5V DC |
| Output Type | Analog (X & Y axes) + Digital (button press) |
| Output Voltage Range | 0V to VCC (proportional to joystick position) |
| Resting Position Output | ~2.5V (mid-range at 5V supply) |
| Potentiometer Resistance | ~10KOhm per axis |
| Button Type | Momentary tactile push-button (press joystick down) |
| Pin Configuration | GND, +5V, VRx (X-axis), VRy (Y-axis), SW (Switch) |
| Interface | 5-pin header (breadboard compatible) |
| Compatible Platforms | Arduino, ESP32, ESP8266, Raspberry Pi, STM32, PIC |
| ADC Resolution Recommended | 10-bit (0-1023 on Arduino) |
| Mechanical Travel | Full 360 degrees movement with spring-loaded self-centering |
| Thumb Cap | Included (press-fit rubber/plastic cap) |
| PCB Dimensions | Approx. 34mm x 26mm |
| Module Weight | ~12g |
| Mounting | Breakout board with header pins for easy prototyping |
| Operating Temperature | -20 degreesC to +70 degreesC |
| Origin | Original/Authentic |
| Warranty | 7-day warranty on manufacturing defects |
| Support | Email & WhatsApp 24/7 |
Key Features
- Dual-Axis Analog Output: Two independent 10KOhm potentiometers provide smooth, proportional analog signals for precise X and Y position tracking across the full range of motion.
- Built-In Push Button: Pressing the joystick knob downward activates a momentary digital switch, adding a third input channel without needing additional components.
- Spring-Loaded Self-Centering: Internal spring mechanism automatically returns the joystick to the neutral center position when released, ensuring consistent and predictable behavior.
- Wide Voltage Compatibility: Operates reliably at both 3.3V and 5V logic levels, making it directly compatible with Arduino Uno, Mega, Nano, ESP32, ESP8266, and Raspberry Pi Pico.
- Breadboard-Friendly Design: Breakout PCB with clearly labeled header pins allows instant plug-and-play connections on breadboards and perfboards without soldering.
- Comfortable Thumb Cap: Includes a textured rubber/plastic cap for comfortable and precise thumb control during extended use.
- Compact Form Factor: Small 34mm x 26mm PCB footprint fits easily into handheld controllers, robot remotes, and space-constrained enclosures.
- Simple Analog Interface: No libraries or complex protocols required - just connect to any ADC pins and read values directly using analogRead().
Pin Configuration
| Pin | Label | Function |
| 1 | GND | Ground connection |
| 2 | +5V | Power supply (3.3V-5V) |
| 3 | VRx | Analog output for X-axis position |
| 4 | VRy | Analog output for Y-axis position |
| 5 | SW | Digital output for push-button switch (active LOW) |
How It Works
The PS2 joystick module contains two potentiometers mounted perpendicular to each other, mechanically linked to the joystick shaft. When you move the joystick along the X-axis (left-right), one potentiometer's resistance changes proportionally. Moving along the Y-axis (up-down) changes the other. These resistance changes produce variable analog voltages on the VRx and VRy output pins, ranging from 0V (one extreme) to VCC (opposite extreme), with approximately half of VCC at the resting center position. The microcontroller's ADC converts these voltages into digital
Frequently Asked Questions
When will I receive my order?
Products ship within 1-5 days from our Bengaluru warehouse. Delivery within 7-8 days to most locations across India.
Is technical support available?
Yes, 24/7 support via email and WhatsApp for setup, troubleshooting, and application guidance.
What is your return policy?
7-day returns on manufacturing defects only. Full refund or replacement. Not applicable for user damage or misuse.
Are bulk discounts available?
Yes, wholesale pricing on orders of 10+ units. Contact us via WhatsApp or email for a custom quote.
Buy PS2 Joystick Module Breakout Sensor Online in India
Purchase the PS2 Joystick Module Breakout Sensor online at The Engineer Store - India's most trusted electronics components store. We deliver across all major cities including Bengaluru, Mumbai, Delhi, Chennai, Hyderabad, Pune, Kolkata, Ahmedabad, Jaipur, and Surat. Get the best price on PS2 Joystick Module Breakout Sensor with fast 1-5 day shipping from our Bengaluru warehouse. All products are 100% authentic, sourced from authorized distributors with 7-day warranty on manufacturing defects.
Looking to buy PS2 Joystick Module Breakout Sensor at the best price in India? The Engineer Store offers competitive pricing, bulk discounts for orders of 10+ units, and dedicated technical support via email and WhatsApp. Whether you are a hobbyist, student, or professional engineer, we have everything you need for your electronics projects.
