Description
1872×1404, 10.3inch Flexible E-Ink Display HAT For Raspberry Pi, IT8951 Controller, USB/SPI/I80 Interface
Overview
This is a flexible E-Ink display HAT for Raspberry Pi, 10.3inch, 1872×1404 resolution, with embedded controller IT8951, communicating via USB/SPI/I80 interface, supports partial refresh.
Compared with normal e-Paper panels, this is a flexible panel and it's thinner and lighter.
Due to the advantages like low power consumption, wide viewing angle, clear display without electricity, it is an ideal choice for applications such as ebook reader, e-ink display, industrial instruments, and so on.
Features
- Flexible e-Paper
- No backlight, keeps displaying last content for a long time even when power down
- Low power consumption, basically power is only required for refreshing
- Standard Raspberry Pi 40PIN GPIO extension header, supports Raspberry Pi series boards
- USB/SPI/I80 interface, for connecting with host boards like Raspberry Pi/Nucleo, etc.
- Comes with development resources and manual (examples for Raspberry Pi/STM32)
e-Paper IT8951 Driver HAT (B) Dimensions
Resources
Package Content
- 10.3inch e-Paper (D) x1
- e-Paper IT8951 Driver HAT (B) x1
- 10.3inch e-Paper Adapter x1
- 40PIN FFC (same side contact) x1
- USB type A plug to micro B plug cable x1
- PH2.0 20cm 8Pin x1
- RPi screws pack (2pcs) x1
FAQs:
Q: What is the resolution of this flexible E-Ink display?
A: The resolution of this display is 1872×1404.
Q: What is the advantage of using a flexible e-Paper panel?
A: The advantage of using a flexible e-Paper panel is that it is thinner and lighter compared to normal e-Paper panels.
Q: Can this display retain its content even when power is down?
A: Yes, this display can keep displaying the last content for a long time even when power is down due to its lack of backlight.
Q: What interface options are available for connecting this display with host boards?
A: This display supports USB/SPI/I80 interface for connecting with host boards like Raspberry Pi and Nucleo.
Q: Which applications is this flexible E-Ink display suitable for?
A: This display is ideal for applications such as ebook readers, e-ink displays, and industrial instruments due to its low power consumption, wide viewing angle, and clear display without electricity.
