1x40 2.54mm Pitch Female Berg Strip Header (Right Angle)

A versatile right-angle female berg strip header featuring 40 pins in a single row with standard 2.54mm (0.1") pitch. Ideal for making perpendicular board-to-board connections, edge-mounted interfaces, and compact PCB layouts where vertical clearance is limited. Available at The Engineer Store, Bengaluru with fast shipping and dedicated support.

Specifications

Key Features

• Right-Angle (90 degrees) Design: Pins exit parallel to the PCB surface, enabling perpendicular board-to-board connections and space-efficient edge-mount configurations.
• Standard 2.54mm Pitch: Universally compatible with breadboards, perfboards, Arduino, Raspberry Pi, and virtually all standard-pitch male headers and ribbon cables.
• 40-Pin Breakable Strip: Easily snap apart into smaller sections (e.g., 1x2, 1x4, 1x6, 1x8, 1x10, 1x20) to match your exact connector requirements.
• Reliable Female Socket Contacts: Precision-formed spring contacts provide secure, low-resistance mating with standard square or round male header pins.
• Gold/Tin-Plated Contacts: Ensures excellent conductivity, corrosion resistance, and long-term connection reliability across hundreds of mating cycles.
• High-Temperature Nylon Insulator: PA66 housing rated UL94V-0 for flame retardancy, with operating temperatures up to +105 degreesC for demanding applications.
• Through-Hole Soldering: Sturdy THT pins for robust mechanical and electrical connections to single or multi-layer PCBs.

Why Choose This?

• 100% authentic from trusted connector suppliers - consistent quality across every strip
• Right-angle orientation solves vertical clearance problems in enclosures and stacked assemblies
• Breakable design means one strip serves dozens of projects - exceptional value
• 1-5 day shipping, 7-8 day delivery from Bengaluru warehouse to most locations across India
• Expert technical support included for connector selection and PCB design guidance

Common Applications

• Board-to-Board Connections: Create perpendicular mating interfaces between two PCBs in stacked or L-shaped configurations.
• Edge-Mount Panel Connectors: Mount headers at the PCB edge for external cable or daughter-board access through enclosure walls.
• Arduino & Raspberry Pi Shields: Build custom shields, HATs, and expansion boards with proper right-angle header interfaces.
• Breadboard & Prototyping: Snap to size and use on perfboards or breadboards for quick signal routing and modular prototyping.
• Ribbon Cable Termination: Accept standard 2.54mm pitch flat ribbon cables with male IDC headers for organized multi-signal wiring.
• Sensor & Module Mounting: Provide socketed connections for plug-in sensor modules, display boards, and communication modules at 90 degrees angles.
• Test Jigs & Fixtures: Build reusable test points and programming interfaces for production and quality assurance setups.

Project Ideas

• Compact IoT Enclosure: Use right-angle headers to connect a sensor daughterboard perpendicular to the main controller PCB, minimizing enclosure height for wall-mounted IoT nodes.
• Modular Robot Controller: Create a backplane with right-angle female headers where motor driver, sensor
