Arduino Robotics Kit for Grade 8 | Ekya School, CMR

The official Arduino Robotics Kit curated specifically for Grade 8 students at Ekya School, CMR campus. This comprehensive kit contains every component needed to complete the school's robotics curriculum, from basic circuit building to programming autonomous robots. Assembled and quality-checked by The Engineer Store, Bengaluru - your trusted education technology partner.

Specifications

Feature	Details
Kit Type	School Robotics & Programming Kit
Grade Level	Grade 8 - Ekya School, CMR Campus
Core Board	Arduino Uno R3 (ATmega328P, Original/Compatible)
Programming Language	Arduino C/C++ via Arduino IDE
Power Supply	USB powered + 9V battery snap connector
Component Count	80+ individual parts
Chassis	2WD smart car chassis with acrylic base plate
Motors	2x BO motors (dual-shaft, 3-6V DC) with wheels
Sensor Suite	Ultrasonic, IR proximity, line-tracking, LDR
Connectivity	USB Type-B cable for programming
Compatibility	Windows, macOS, Linux (Arduino IDE)
Skill Level	Beginner to Intermediate
Curriculum Aligned	Ekya School Grade 8 Robotics Syllabus
Origin	Authentic components, quality-verified
Warranty	1 Year from The Engineer Store
Support	Email & WhatsApp 24/7 + School Lab Support

What's Included in the Kit

Core Electronics

• 1x Arduino Uno R3 board with USB cable
• 1x Motor driver shield (L293D / L298N based)
• 1x Half-size solderless breadboard (400 tie-points)
• 1x 9V battery snap connector with DC barrel jack

Robotics Chassis & Motion

• 1x 2WD smart car acrylic chassis plate
• 2x BO gear motors (dual shaft, 150 RPM)
• 2x Rubber wheels (65mm diameter)
• 1x 360 degrees castor wheel (front swivel)
• Mounting hardware (brass standoffs, screws, nuts)

Sensors

• 1x HC-SR04 ultrasonic distance sensor
• 2x IR proximity/obstacle avoidance sensors
• 1x TCRT5000 line-tracking sensor module (3-channel)
• 2x LDR (light-dependent resistor) modules

Output Components

• 5x LEDs (red, green, yellow, blue, white)
• 1x Active buzzer module
• 1x Passive buzzer
• 1x SG90 micro servo motor (9g)
• 1x 16x2 LCD display (I2C interface)

Basic Components

• 30x Resistors (assorted: 220Ohm, 330Ohm, 1KOhm, 10KOhm)
• 5x Push buttons (tactile switches)
• 2x Potentiometers (10KOhm rotary)
• 1x RGB LED (common cathode)
• 3x NPN transistors (BC547)
• 5x Diodes (1N4007)
• 10x Capacitors (assorted ceramic & electrolytic)

Wiring & Connectivity

• 40x Male-to-male jumper wires
• 40x Male-to-female jumper wires
• 20x Female-to-female jumper wires
• 1x USB Type-B programming cable (1.5m)
• Cable ties and wire organizer strips

Documentation & Learning Materials

• 1x Printed quick-start guide
• 1x Component identification card
• Access to online project tutorials (QR code linked)
• Ekya School curriculum project sheets (digital)
• Arduino IDE installation guide

Storage

• 1x Durable compartmentalized plastic organizer box
• Component labels and divider cards

Curriculum Projects Covered

Term 1 - Foundations

• Project 1: LED Blink & Traffic Light - Learn digital output, delays, and sequential logic by building a working traffic signal.
• Project 2: Button-Controlled LED - Understand digital input, pull-up resistors, and conditional programming.
• Project 3: Light Sensor Night Lamp - Use LDR modules to create an automatic light that responds to ambient brightness.
• Project 4: Buzzer Piano - Program different tones using push buttons and a passive buzzer to create a mini musical instrument.

Term 2 - Robotics & Automation

• Project 5: 2WD Robot Assembly - Build the complete robot chassis, wire motors to the driver shield, and test basic movement commands.
• Project 6: Obstacle-Avoiding Robot - Program the ultrasonic sensor to detect walls and autonomously navigate around obstacles.
• Project 7: Line-Following Robot - Use IR/line-tracking sensors to build a robot that follows a black line on a white surface.
• Project 8: Servo-Controlled Scanning Robot - Mount the servo with the ultrasonic sensor to create a scanning mechanism for smarter navigation.

Term 3 - Advanced Integration

• Project 9: LCD Dashboard Robot - Display real-time sensor readings (distance, light level) on the I2C LCD screen while the robot operates.
• Project 10: Final Capstone Challenge - Students design and program a custom robot behavior combining multiple sensors, outputs, and logic for the end-of-year showcase.

Why This Kit is Perfect for Ekya School Students

• Curriculum-matched - Every component maps directly to the Grade 8 robotics syllabus at Ekya School, CMR. No missing parts, no unnecessary extras.
• Pre-sorted and labeled - Components arrive organized in a compartmentalized box with clear labels, so students spend time learning, not searching.
• Tested before shipping - Each Arduino board is upload-tested and every sensor is functionality-verified at our Bengal

Frequently Asked Questions

When will I receive my order?

Products ship within 1-5 days from our Bengaluru warehouse. Delivery within 7-8 days to most locations across India.

Is technical support available?

Yes, 24/7 support via email and WhatsApp for setup, troubleshooting, and application guidance.

What is your return policy?

7-day returns on manufacturing defects only. Full refund or replacement. Not applicable for user damage or misuse.

Are bulk discounts available?

Yes, wholesale pricing on orders of 10+ units. Contact us via WhatsApp or email for a custom quote.
