PAM 8403 Amplifier Module with Knob
Compact, high-efficiency Class-D stereo amplifier module powered by the PAM8403 IC, featuring an onboard potentiometer knob for convenient volume control. Delivers crisp 2x3W audio output from a 5V USB-compatible power supply - ideal for portable speakers, DIY audio projects, and embedded sound systems. Available at The Engineer Store, Bengaluru with fast shipping and full technical support.
Specifications
| Amplifier IC | PAM8403 Class-D Stereo Audio Amplifier |
| Output Power | 2 x 3W (4Ohm load, 5V supply) |
| Operating Voltage | 2.5V - 5.5V DC (5V recommended) |
| Audio Channels | 2 (Stereo - Left & Right) |
| THD+N (Total Harmonic Distortion) | <= 0.1% at 1kHz, 1W output |
| SNR (Signal-to-Noise Ratio) | >= 80dB |
| Efficiency | Up to 90% (Class-D switching topology) |
| Volume Control | Onboard rotary potentiometer knob |
| Audio Input | 3.5mm stereo AUX / solder pads (L, R, GND) |
| Speaker Output | Screw terminals / solder pads for Left & Right speakers |
| Recommended Speaker Impedance | 4Ohm - 8Ohm |
| Quiescent Current | ~10mA (low standby power consumption) |
| Board Dimensions | Approx. 30mm x 25mm x 12mm (compact form factor) |
| Mounting | PCB mounting holes for secure installation |
| Operating Temperature | -40 degreesC to +85 degreesC |
| Features | Filterless output, short-circuit protection, thermal shutdown |
| Warranty | 7-day warranty on manufacturing defects |
| Support | Email & WhatsApp 24/7 |
Key Features
- Class-D Efficiency: Up to 90% power efficiency means minimal heat generation, eliminating the need for bulky heatsinks and making it perfect for battery-powered projects.
- Integrated Volume Knob: Onboard potentiometer provides smooth, hands-on volume adjustment without requiring external controls or software.
- USB-Compatible 5V Operation: Runs directly from USB power banks, phone chargers, Arduino 5V pins, or any standard 5V DC source for maximum versatility.
- True Stereo Output: Dual-channel amplification drives two separate speakers for genuine left/right stereo sound separation.
- Filterless Design: PAM8403's filterless architecture reduces external component count, board size, and overall system cost.
- Built-In Protection: Thermal shutdown and short-circuit protection safeguard both the module and your speakers from damage.
- Ultra-Compact Footprint: Tiny PCB fits inside portable speaker enclosures, small robots, wearable devices, and tight project housings.
- Plug-and-Play Simplicity: Just connect power, audio input, and speakers - no additional driver circuits, capacitors, or configuration needed.
Why Choose The PAM 8403 Amplifier Module with Knob?
- 100% authentic modules sourced directly from trusted, authorized component suppliers
- Tested and quality-checked at our Bengaluru warehouse before dispatch
- 1-5 day shipping, 7-8 day delivery across India; same-day delivery available in Bengaluru
- Expert technical support to help with wiring, integration, and troubleshooting
- Unbeatable price-to-performance ratio for audio amplification projects
Project Ideas
- DIY Portable Bluetooth Speaker: Pair with a Bluetooth audio receiver module (e.g., HC-05 or dedicated BT board), two 4Ohm/8Ohm speakers, and a USB power bank to build a fully wireless portable speaker system with volume control.
- Arduino/Raspberry Pi Sound System: Connect to the audio output of a Raspberry Pi, ESP32 with I2S DAC, or Arduino with DFPlayer Mini to add amplified sound to interactive projects, voice assistants, or notification systems.
- Desktop PC/Laptop Mini Speakers: Build a compact, custom stereo speaker set powered directly from a USB port - perfect for workstations where space is limited.
- Robot Voice & Sound Effects: Integrate into robotics projects to amplify pre-recorded voice prompts, alert tones, or music for interactive robots and smart devices.
- Intercom or PA System Prototype: Use as the amplification stage in a small-scale intercom, classroom announcement system, or doorbell speaker module.
- Guitar Practice Amp
Frequently Asked Questions
When will I receive my order?
Products ship within 1-5 days from our Bengaluru warehouse. Delivery within 7-8 days to most locations across India.
Is technical support available?
Yes, 24/7 support via email and WhatsApp for setup, troubleshooting, and application guidance.
What is your return policy?
7-day returns on manufacturing defects only. Full refund or replacement. Not applicable for user damage or misuse.
Are bulk discounts available?
Yes, wholesale pricing on orders of 10+ units. Contact us via WhatsApp or email for a custom quote.
Buy PAM 8403 Amplifier Module with Knob Online in India
Purchase the PAM 8403 Amplifier Module with Knob online at The Engineer Store - India's most trusted electronics components store. We deliver across all major cities including Bengaluru, Mumbai, Delhi, Chennai, Hyderabad, Pune, Kolkata, Ahmedabad, Jaipur, and Surat. Get the best price on PAM 8403 Amplifier Module with Knob with fast 1-5 day shipping from our Bengaluru warehouse. All products are 100% authentic, sourced from authorized distributors with 7-day warranty on manufacturing defects.
Looking to buy PAM 8403 Amplifier Module with Knob at the best price in India? The Engineer Store offers competitive pricing, bulk discounts for orders of 10+ units, and dedicated technical support via email and WhatsApp. Whether you are a hobbyist, student, or professional engineer, we have everything you need for your electronics projects.
