Raspberry Pi Compute Module 5 (CM5) Lite 8GB - Industrial SoM (CM5008000)
ଦ୍ .ାରା
Raspberry Pi
SKU: TES-raspberry-pi-compute-module-5-cm5-lite-8gb-industrial-som-cm5008000
Raspberry Pi Compute Module 5 (CM5) Lite 8GB - Industrial SoM (CM5008000)
Elevate Your Industrial Projects with Raspberry Pi Compute Module 5 (CM5) Lite 8GB
The Raspberry Pi Compute Module 5 (CM5) Lite 8GB (Part Number: CM5008000) is a high-performance System-on-Module (SoM) designed for professional and industrial integration. Powered by the Broadcom BCM2712 quad-core 64-bit Arm Cortex-A76 processor running at 2.4GHz, this module delivers twice the performance of its predecessor, making it the perfect choice for edge computing, high-end automation, and data-intensive applications.
Enterprise-Grade Power in a Compact Design
Measuring just 55mm x 40mm, the CM5008000 fits seamlessly into custom carrier boards, providing the robust computing power of the Raspberry Pi 5 without the overhead of standard consumer ports. With 8GB of LPDDR4X-4267 SDRAM, this variant offers the ideal balance of memory and efficiency for modern embedded systems.
Key Technical Specifications
- Processor: Broadcom BCM2712 Quad-core Arm Cortex-A76 @ 2.4GHz
- Memory: 8GB LPDDR4X-4267 SDRAM - high-bandwidth memory for demanding workloads.
- Lite Design: No onboard eMMC; allows for custom storage solutions via microSD, NVMe SSD, or external eMMC on the carrier board.
- Connectivity: Gigabit Ethernet PHY, 2x USB 3.0 (5Gbps), and 1x USB 2.0 interface.
- High-Speed Expansion: Single-lane PCIe Gen 2.0 interface for connecting NVMe drives and other peripherals.
- Multimedia: Dual 4Kp60 HDMI output support, 4Kp60 HEVC decoder, and OpenGL ES 3.1 / Vulkan 1.2 graphics.
Why Choose the CM5 Lite 8GB for Your Build?
The "Lite" version offers maximum flexibility for developers who require customized storage configurations. Whether you need the high speed of an NVMe SSD for AI inference or the durability of an industrial-grade microSD card, the CM5008000 adapts to your architecture. Its non-wireless design is specifically tailored for environments where security and wired connectivity are paramount.
Frequently Asked Questions (FAQ)
1. Does this version include Wi-Fi or Bluetooth?
No, the CM5008000 is a non-wireless variant. It is designed for applications where wired connectivity (Gigabit Ethernet) is preferred for stability and security.
2. Can I use this with my existing CM4 IO Board?
Yes, the CM5 is designed to be compatible with most CM4 carrier boards, as it uses the same dual 100-pin high-density connectors. Always check power requirements, as the CM5 may draw more peak current than the CM4.
3. How do I add storage to this "Lite" module?
Since this is a Lite version without onboard eMMC, storage must be provided via the carrier board. You can use a microSD card slot, an eMMC module, or an M.2 NVMe SSD via the PCIe interface.
4. Is the processor faster than the one in the Compute Module 4?
Yes, significantly. The BCM2712 processor in the CM5 is based on the Cortex-A76 architecture, offering roughly 2x to 3x the performance of the BCM2711 used in the CM4.
5. What are the typical use cases for the 8GB variant?
The 8GB RAM variant is excellent for memory-intensive tasks such as running multiple Docker containers, lightweight server workloads, complex machine vision, and digital signage with heavy assets.
