TB6600 Stepper Motor Driver
High-performance stepper motor driver designed for CNC machines, 3D printers, and precision motion control systems. The TB6600 delivers smooth, reliable microstepping with adjustable current control up to 4A, supporting both bipolar and hybrid stepper motors for professional-grade automation projects.
Specifications
| Driver Chip | TB6600HG (Toshiba) |
| Input Voltage | 9V-42V DC |
| Output Current (Max) | 4.0A per phase (peak) |
| Output Current (RMS) | 0.5A-3.5A (adjustable via DIP switches) |
| Micro-Step Modes | 1, 2, 4, 8, 16, 32 (selectable via DIP switches) |
| Compatible Motors | 2-phase, 4-wire / 6-wire bipolar & hybrid stepper motors (NEMA 17, NEMA 23) |
| Signal Input | PUL+/PUL, DIR+/DIR, ENA+/ENA (optocoupler isolated) |
| Signal Input Voltage | 3.3V-24V DC (compatible with Arduino, Raspberry Pi, PLC, Mach3) |
| Max Pulse Frequency | 200 kHz |
| Protection Features | Over-current, over-temperature, under-voltage lockout |
| Cooling | Built-in aluminum heatsink with integrated cooling fan |
| Housing Material | CNC-machined aluminum alloy enclosure |
| Mounting | 4x M3 screw holes for panel/DIN rail mounting |
| Dimensions | 96 x 56 x 33 mm (approx.) |
| Weight | ~200g |
| Operating Temperature | 10 degreesC to +45 degreesC |
| Warranty | 7-day warranty on manufacturing defects |
| Support | Email & WhatsApp 24/7 |
Why Choose the TB6600 Stepper Motor Driver?
- Wide Voltage & Current Range: Operates from 9V to 42V DC with adjustable current output up to 4A, making it versatile enough for small NEMA 17 motors through powerful NEMA 23 stepper motors.
- 32-Microstep Resolution: Six selectable microstepping modes (full-step to 1/32) via onboard DIP switches deliver ultra-smooth motion, reduced vibration, and quieter operation for precision applications.
- Optocoupler-Isolated Inputs: Fully isolated signal inputs protect your controller board from electrical noise and ground loops, ensuring reliable communication with Arduino, Raspberry Pi, Mach3, LinuxCNC, and industrial PLCs.
- Built-In Thermal Management: The Engineer Store aluminum heatsink housing combined with an integrated cooling fan ensures stable operation during extended high-current runs without thermal throttling.
- Comprehensive Protection Circuitry: Over-current, over-temperature, and under-voltage protection safeguard both the driver and your stepper motor from damage during fault conditions.
- Easy DIP Switch Configuration: No software required - simply set current limit and microstep resolution using clearly labeled onboard DIP switches with reference tables printed on the enclosure.
- 100% Authentic Components: Sourced directly from authorized distributors with verified Toshiba TB6600HG chipset for guaranteed performance and longevity.
- Fast Shipping from Bengaluru: 1-5 day shipping, 7-8 day delivery across India, with same-day dispatch available for Bengaluru orders.
Project Ideas
- CNC Router / Milling Machine: Use the TB6600 to drive X, Y, and Z axis stepper motors on your DIY or upgraded CNC machine. Pair with Mach3, GRBL, or LinuxCNC for precise toolpath control and smooth cutting operations on wood, acrylic, aluminum, and PCBs.
- 3D Printer Build or Upgrade: Replace underpowered A4988 or DRV8825 drivers with the TB6600 for larger print volumes using NEMA 23 motors. Achieve faster print speeds and improved layer consistency on CoreXY, Cartesian, or delta printer frames.
- Laser Engraver / Cutter: Drive the gantry system of a CO2 or diode laser cutter with precise microstepping for clean engraving lines and accurate cutting paths on wood, leather, fabric, and acrylic.
- Camera Slider & Motion Control Rig: Build a motorized camera slider or pan-tilt system for time-lapse photography and cinematic video. The 1/32 microstepping ensures buttery-smooth, jitter-free motion at very slow speeds.
- Automated Conveyor & Pick-and-Place Systems: Integrate into factory automation, packaging lines, or robotic pick-and-place setups where repeatable, programmable linear or rotary motion is required.
Frequently Asked Questions
When will I receive my order?
Products ship within 1-5 days from our Bengaluru warehouse. Delivery within 7-8 days to most locations across India.
Is technical support available?
Yes, 24/7 support via email and WhatsApp for setup, troubleshooting, and application guidance.
What is your return policy?
7-day returns on manufacturing defects only. Full refund or replacement. Not applicable for user damage or misuse.
Are bulk discounts available?
Yes, wholesale pricing on orders of 10+ units. Contact us via WhatsApp or email for a custom quote.
Buy TB6600 Stepper Motor Driver Online in India
Purchase the TB6600 Stepper Motor Driver online at The Engineer Store - India's most trusted electronics components store. We deliver across all major cities including Bengaluru, Mumbai, Delhi, Chennai, Hyderabad, Pune, Kolkata, Ahmedabad, Jaipur, and Surat. Get the best price on TB6600 Stepper Motor Driver with fast 1-5 day shipping from our Bengaluru warehouse. All products are 100% authentic, sourced from authorized distributors with 7-day warranty on manufacturing defects.
Looking to buy TB6600 Stepper Motor Driver at the best price in India? The Engineer Store offers competitive pricing, bulk discounts for orders of 10+ units, and dedicated technical support via email and WhatsApp. Whether you are a hobbyist, student, or professional engineer, we have everything you need for your electronics projects.
