43% off
17HS3401S NEMA17 Stepper Motor
High-precision NEMA17 bipolar stepper motor ideal for 3D printers, CNC machines, laser engravers, and robotics projects. The 17HS3401S delivers reliable 1.3A per phase performance with a compact 34mm body length, smooth 1.8 degrees step angle, and excellent holding torque for accurate motion control. Available from The Engineer Store, Bengaluru with fast shipping, 7-day warranty on manufacturing defects, and dedicated technical support.
Specifications
| Motor Type | Bipolar Hybrid Stepper Motor |
| NEMA Frame Size | NEMA 17 (42mm x 42mm faceplate) |
| Model Number | 17HS3401S |
| Step Angle | 1.8 degrees (200 steps per revolution) |
| Rated Current | 1.3A per phase |
| Rated Voltage | 2.4V DC |
| Phase Resistance | 1.8Ohm per phase |
| Phase Inductance | 2.5mH per phase |
| Holding Torque | 28 Ncm (40 ozin) |
| Detent Torque | 1.6 Ncm |
| Number of Phases | 2 |
| Number of Leads | 4 wires |
| Body Length | 34mm |
| Shaft Diameter | 5mm (D-shaft) |
| Shaft Length | 22mm |
| Motor Weight | Approx. 220g |
| Insulation Class | Class B |
| Operating Temperature | -20 degreesC to +50 degreesC |
| Mounting Holes | M3, 31mm spacing (NEMA17 standard) |
| Compatibility | A4988, DRV8825, TMC2208, TMC2209, TB6600 drivers |
| Origin | Original/Authentic |
| Warranty | 7-day warranty on manufacturing defects |
| Support | Email & WhatsApp 24/7 |
Why Choose the 17HS3401S NEMA17 Stepper Motor?
- Precise 1.8 degrees Step Angle: 200 steps per revolution ensures smooth, accurate positioning for 3D printing, CNC routing, and laser engraving applications
- Reliable 28 Ncm Holding Torque: Provides strong positional hold and consistent movement under load without missed steps
- Compact 34mm Body: Shorter body length fits tight enclosures and lightweight gantry systems while delivering ample torque
- Universal 4-Wire Bipolar Design: Simple wiring compatible with all popular stepper drivers including A4988, DRV8825, TMC2208, TMC2209, and TB6600
- Standard NEMA17 Mounting: Drop-in replacement for any NEMA17 application with standard 42mm x 42mm faceplate and 31mm M3 hole pattern
- 5mm D-Shaft: Flat-sided shaft prevents coupler slippage and works directly with GT2 pulleys, flexible couplings, and lead screw connectors
- Low Power Consumption: 1.3A rated current keeps driver and power supply requirements modest, reducing overall system cost
- 100% Authentic: Sourced directly from trusted, authorized suppliers with full quality verification
- Fast 1-5 days shipping: Ships from our Bengaluru warehouse to most locations across India; same-day delivery available in Bengaluru
- Expert Technical Support: Full wiring guidance, driver configuration help, and troubleshooting assistance included at no extra cost
Project Ideas
- 3D Printer Build or Upgrade: Use as X, Y, or extruder motor in Prusa i3, Ender 3 clones, CoreXY, and custom RepRap 3D printers for smooth, precise layer-by-layer printing
- CNC Machine & Router: Drive the axes of a desktop CNC mill or PCB router with accurate step control for clean cuts and engravings
- Laser Engraver / Cutter: Power the XY gantry of a diode laser engraver for detailed artwork, signage, and material cutting
- Camera Slider & Pan-Tilt System: Build a motorized camera slider or time-lapse pan-tilt head with ultra-smooth, programmable motion
- Robotic Arm & Automation: Actuate joints in a robotic arm, automated turntable, pick-and-place machine, or conveyor belt
Frequently Asked Questions
When will I receive my order?
Products ship within 1-5 days from our Bengaluru warehouse. Delivery within 7-8 days to most locations across India.
Is technical support available?
Yes, 24/7 support via email and WhatsApp for setup, troubleshooting, and application guidance.
What is your return policy?
7-day returns on manufacturing defects only. Full refund or replacement. Not applicable for user damage or misuse.
Are bulk discounts available?
Yes, wholesale pricing on orders of 10+ units. Contact us via WhatsApp or email for a custom quote.
Buy 17HS3401S NEMA17 Stepper Motor Online in India
Purchase the 17HS3401S NEMA17 Stepper Motor online at The Engineer Store - India's most trusted electronics components store. We deliver across all major cities including Bengaluru, Mumbai, Delhi, Chennai, Hyderabad, Pune, Kolkata, Ahmedabad, Jaipur, and Surat. Get the best price on 17HS3401S NEMA17 Stepper Motor with fast 1-5 day shipping from our Bengaluru warehouse. All products are 100% authentic, sourced from authorized distributors with 7-day warranty on manufacturing defects.
Looking to buy 17HS3401S NEMA17 Stepper Motor at the best price in India? The Engineer Store offers competitive pricing, bulk discounts for orders of 10+ units, and dedicated technical support via email and WhatsApp. Whether you are a hobbyist, student, or professional engineer, we have everything you need for your electronics projects.
