Solenoid Valve 230V AC
High-performance 230V AC solenoid valve from The Engineer Store, Bengaluru. Engineered for reliable fluid and gas control in automation, irrigation, and industrial systems. Fast shipping, 7-day warranty on manufacturing defects, and dedicated technical support.
Specifications
| Type | 2-Way Normally Closed (NC) Solenoid Valve |
| Operating Voltage | 230V AC, 50/60 Hz |
| Body Material | Brass / Stainless Steel |
| Seal Material | NBR (Nitrile Buna Rubber) |
| Port Size | 1/2" BSP (common variant) |
| Operating Pressure | 0 - 10 bar (model dependent) |
| Media Compatibility | Water, Air, Light Oils, Inert Gases |
| Response Time | ~20-50 ms (open), ~30-80 ms (close) |
| Coil Class | Class F Insulation (155 degreesC) |
| Protection Rating | IP65 (dust-tight, water-jet resistant) |
| Duty Cycle | Continuous (100%) |
| Operating Temperature | -10 degreesC to +80 degreesC |
| Coil Power Consumption | ~8-15 W |
| Connection Type | DIN 43650 Connector (included) |
| Origin | Original / Authentic - Industrial Grade |
| Warranty | 7-day warranty on manufacturing defects |
| Support | Email & WhatsApp 24/7 |
Product Description
This 230V AC solenoid valve is a robust, electrically actuated shut-off valve designed for precise on/off control of water, air, light oils, and inert gases. When the coil is energized at 230V AC, the plunger lifts to open the valve orifice, allowing media to flow. When de-energized, an internal spring returns the plunger to the closed position, providing a fail-safe normally closed configuration.
Built with a durable brass or stainless steel body and high-temperature NBR seals, this valve withstands demanding environments in factories, agricultural fields, and building management systems. The Class F insulation coil supports continuous duty operation without overheating, while the IP65-rated housing protects against dust ingress and water jets - making it suitable for both indoor and outdoor installations.
The DIN 43650 connector ensures standardized, secure electrical connections compatible with most industrial control panels, PLCs, and relay modules. Whether you're automating a drip irrigation system, controlling coolant flow in a CNC machine, or managing compressed air lines, this solenoid valve delivers consistent, long-life performance.
Key Features
- 230V AC Direct Drive: Operates directly on Indian mains voltage - no step-down transformer or driver circuit required.
- Normally Closed (NC) Design: Fail-safe operation ensures the valve closes automatically during power failure, preventing uncontrolled flow.
- Fast Response Time: Opens in ~20-50 ms for rapid, precise fluid control in automated sequences.
- Continuous Duty Rated: 100% duty cycle with Class F insulation allows uninterrupted operation without coil burnout.
- IP65 Protection: Dust-tight and resistant to low-pressure water jets - ideal for harsh industrial and outdoor environments.
- Brass / Stainless Steel Construction: Corrosion-resistant body ensures long service life with water, air, and light oil media.
- NBR Seals: Excellent chemical resistance and flexibility across a wide temperature range (-10 degreesC to +80 degreesC).
- Standard DIN 43650 Connector: Plug-and-play wiring with industrial-standard connector for clean, reliable electrical hookup.
- Compact & Lightweight: Space-efficient design fits easily into tight piping layouts and control cabinets.
- Wide Media Compatibility: Suitable for water, compressed air, nitrogen, argon, and non-aggressive light oils.
Why Choose This Solenoid Valve?
- 100% Authentic & Industrial Grade: Sourced directly from authorized manufacturers - no clones or refurbished units.
- Mains-Ready for India: Designed for 230V AC / 50 Hz, perfectly matched to the Indian power grid without adapters.
- Proven Reliability: Rated for 500,000+ cycles under normal operating conditions for years of maintenance-free service.
- 1-5 days shipping: Dispatched from our Bengaluru warehouse; same-day delivery available within Bengaluru city.
- Expert Technical Support: Our engineers help you with sizing, installation, wiring, and PLC integration - 24/7 via WhatsApp and email.
- Bulk & OEM Friendly: Wholesale pricing and custom configurations
Frequently Asked Questions
When will I receive my order?
Products ship within 1-5 days from our Bengaluru warehouse. Delivery within 7-8 days to most locations across India.
Is technical support available?
Yes, 24/7 support via email and WhatsApp for setup, troubleshooting, and application guidance.
What is your return policy?
7-day returns on manufacturing defects only. Full refund or replacement. Not applicable for user damage or misuse.
Are bulk discounts available?
Yes, wholesale pricing on orders of 10+ units. Contact us via WhatsApp or email for a custom quote.
Buy Solenoid valve 230v Online in India
Purchase the Solenoid valve 230v online at The Engineer Store - India's most trusted electronics components store. We deliver across all major cities including Bengaluru, Mumbai, Delhi, Chennai, Hyderabad, Pune, Kolkata, Ahmedabad, Jaipur, and Surat. Get the best price on Solenoid valve 230v with fast 1-5 day shipping from our Bengaluru warehouse. All products are 100% authentic, sourced from authorized distributors with 7-day warranty on manufacturing defects.
Looking to buy Solenoid valve 230v at the best price in India? The Engineer Store offers competitive pricing, bulk discounts for orders of 10+ units, and dedicated technical support via email and WhatsApp. Whether you are a hobbyist, student, or professional engineer, we have everything you need for your electronics projects.
