Arducam B0262 12MP IMX477 Mini High Quality Camera Module

द्वारा My Store
SKU: TES-EV00082104
नियमित रूप से मूल्य Rs. 7,389.00 Rs. 6,389.00 14 % छूट
यूनिट मूल्य
प्रति
कोई समीक्षा नहीं

Arducam B0262 12MP IMX477 Mini High Quality Camera Module

Raspberry Pi Camera Module 3 is the latest camera model released by Raspberry Pi Official in 2023. Arducam has designed two Fixed-Focus camera variants before. This camera adopts the Sony 11.9MP IMX708 Image Sensor which can be used to take full HD video as well as still photographs and features an HDR mode of up to 3 megapixels.
The camera is equipped with a 120° wide-angle M12 Lens. Wide-Angle Lens always has a deeper depth of field which can effectively reduce bokeh. A manual focus camera allows you to use it in situations such as macro photographs, low light, etc. where autofocus is difficult to achieve. Meanwhile, it is native to Raspberry Pi and fully supported by libcamera and Picamera2 library.



Technical Specifications

Name B0310
IMAGE SENSOR IMX708
Still Resolution 11.9 Megapixels
Video Modes 2304 × 1296p56, 2304 × 1296p30 HDR, 1536 × 864p120
Sensor Resolution 4608 x 2592 pixels
Sensor image area 6.45 x 3.63mm (7.4mm diagonal)
Pixel Size 1.4μm × 1.4μm
Optical Size 1/2.43"
IR Sensitivity Integral IR-cut Filter, visible light only
FOCUS TYPE MANUAL FOCUS
Focal Length 2.87mm
F.NO F2.8
Field of View(FOV) 152°(D)x120°(H)x66°(V)
Lens Mount M12
CAMERA BOARD SIZE 25 × 24MM
