FT232 USB UART Board (Type A), USB To UART (TTL) Communication Module With USB Type A Connector
द्वारा
My Store
SKU: TES-EVWRIED27
58 % छूट
FT232 USB UART Board (Type A), USB To UART (TTL) Communication Module With USB Type A Connector
This is a FT232 USB To UART (TTL) Communication Module, USB Type A Connector. It Adopts FT232RL, Compatible With 3.3V/5V Logic Level.
User Manual / Datasheet / Example Codes Etc.
Features
- Original FT232RL onboard
- Supports Mac, Linux, Android, WinCE, Windows 7/8/8.1/10/11...
- 3 power mode : 5V output, 3.3V output, or powered by target board (3.3V-5V)
- 3 LEDs: TXD LED, RXD LED, POWER LED
- Functional Pins
- TXD, RXD, RTS#, CTS# : connected to the onboard soldered pinheaders
- The other Pins : accessable on the drill holes (separate pinheaders are also provided for easily connecting to user system, the pitch is compatible with bread boards)
Package Includes
- 1x FT232 USB UART Board (Type A)
- 2x 5-pin male pinheader & 5-pin female pinheader
- 1x 6-pin custom connector jumper wire
How to Use
In the case of working with a MCU:
- VCCIO ↔ 3.3V or 5V output (the module is powered from USB, onboard jumper should be shorted to 3.3V or 5V)
- GND ↔ GND
- TXD ↔ MCU.RX (signal direction: MCU.RX << FT232 << PC.TX)
- RXD ↔ MCU.TX (signal direction: MCU.TX >> FT232 >> PC.RX)
- RTS ↔ MCU.CTS (signal direction: MCU.CTS << FT232 << PC.RTS)
- CTS ↔ MCU.RTS (signal direction: MCU.RTS >> FT232 >> PC.CTS)
Dimensions
