Arducam B0272 12MP IMX477 Motorized Focus High Quality Camera
This Arducam IMX477 High Quality motorized focus camera module integrates a motor that could be controlled by software for a smarter focus, and you will no longer focus the camera by screwing the lens with your bare hands. Instead, keyboard keys or OpenCV can be used to remotely control the focusing process of your HQ camera. To learn more about autofocus with Raspberry Pi camera modules, we recommend you read Raspberry Pi Camera Autofocus: The Complete Guide.
Technical Specifications
| Model | B0272 |
|---|---|
| Sensor | Sony 12.3MP IMX477 |
| Optical Format | 1/2.3″ (diagonal 7.857mm) |
| Resolution | 12.3MP |
| Active Pixels | 4056(H) x 3040(V) |
| Pixel Size | 1.55um x 1.55um |
| Frame Rates | 1080p30fps, 720p60fps and 640 × 480p60/90fps |
| Shutter Type | Rolling Shutter |
| Interface | 2-lane MIPI CSI-2 |
| Default Lens Mount | M12 Mount |
| Focus Distance | 80mm to infinity |
| Field of View(FoV) | 75°(H) |
| IR Sensitivity | Integral IR fliter, visible light only |
| Board Size | 38mm x 38mm |
Arducam B0272 12MP IMX477 Motorized Focus High Quality Camera
This Arducam IMX477 High Quality motorized focus camera module integrates a motor that could be controlled by software for a smarter focus, and you will no longer focus the camera by screwing the lens with your bare hands. Instead, keyboard keys or OpenCV can be used to remotely control the focusing process of your HQ camera. To learn more about autofocus with Raspberry Pi camera modules, we recommend you read Raspberry Pi Camera Autofocus: The Complete Guide.
Technical Specifications
| Model | B0272 |
|---|---|
| Sensor | Sony 12.3MP IMX477 |
| Optical Format | 1/2.3″ (diagonal 7.857mm) |
| Resolution | 12.3MP |
| Active Pixels | 4056(H) x 3040(V) |
| Pixel Size | 1.55um x 1.55um |
| Frame Rates | 1080p30fps, 720p60fps and 640 × 480p60/90fps |
| Shutter Type | Rolling Shutter |
| Interface | 2-lane MIPI CSI-2 |
| Default Lens Mount | M12 Mount |
| Focus Distance | 80mm to infinity |
| Field of View(FoV) | 75°(H) |
| IR Sensitivity | Integral IR fliter, visible light only |
| Board Size | 38mm x 38mm |
