Ebyte MA01-AACX2220 RS485 2DI+2AI+2DO ModBus RTU I/O Module with Serial Port
by
My Store
SKU: TES-EVWRIED18
67% off
Ebyte MA01-AACX2220 RS485 2DI+2AI+2DO ModBus RTU I/O Module with Serial Port
MA01-AACX2220 supports the acquisition of 2-channel sensor switch input (DI) and 2-channelsensor analog input (AI) which are converted to serial port (RS485) and data is transmitted to configuration software or PLC. The serial port I/O networking module (also known as "remote IO") that controls 2 relay switch outputs (DO) by issuing commands through the serial port to realize remote acquisition and control functions.
Features
- Support Modbus RTU protocol
- Support various configuration software/PLC/touch screen
- RS485 acquisition and control IO
- DC 8～28V power supply
- 2-channel switch input DI (dry node)
- 2-channel analog input AI (0～20mA/4～20mA)
- 2-channel switch output DO (relay)
- Switch input (DI) supports counting function
- Switch input (DI) supports rising edge, falling edge, and level trigger mode
- Switch output (DO) supports level mode, pulse mode, follow mode
- Communication baud rate 1200～115200 (default 9600), support customsetting
- Supports 1～247 slave stations, 5-digit DIP switch can set 1～31 address code, more than31canbe set by software
- Supports installation of guide and positioning hole
